What it welds
The Weldpro 200A Multi-Process Welder is a multi-process with a maker-stated output of up to 200 amps on 220-volt input.
Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 200 amps at roughly 0.200 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: TIG/Stick. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.
It needs a 240-volt circuit; have a licensed electrician install the receptacle the manual specifies. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 10 for most of this machine's range (shade 10 for stick above 160 A). Full table.
Also on the listing: dimensions of 17.6 x 7.9 x 16.2 inches and a weight of 61.8 lb.
Is it the right machine for the job?
Buy it for
- A shop that does a bit of everything
- Steel to about 0.200 in per pass
Skip it for
- Steel much past 0.200 in in one pass
What it does well, where it falls short
Does well
- Up to 200 A output
- Multi-process
- Pulse: AC Pulse TIG
Falls short
- Duty cycle not stated with amps
- Needs a 240 V circuit
- Torches may be extra
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | 200A | Retailer |
|---|---|---|
| Product weight | 61.8 lb | Retailer |
| Dimensions (seller) | 17.6 x 7.9 x 16.2 inches | Retailer |
| Size | 61.8 lb | Retailer |
| Material | Metal | Retailer |
| Power | ac_dc | Retailer |
| Input power | 220 V | Retailer |
| Wattage | 44 KW | Retailer |
| Output range | 200a | Retailer |
| Processes | TIG/Stick | Retailer |
| AC / DC | ac/dc | Retailer |
| Pulse | AC Pulse TIG | Retailer |
Machines to put next to it
Other multi-process welders in the same amp range
- ARCCAPTAIN MIG205MP Multi-Process Welder
- Weldpro OMNI210-KT26 Torch Multi-Process Welder
- Eastwood MIG 180 Multi-Process Welder
- ESAB Rebel EMP 215ic Multi-Process Welder
Every multi-process welders on one spec sheet · All Weldpro machines listed
Final verdict
Built for A shop that does a bit of everything.
