Lincoln Electric K5255-1 Flux-Core Welder: 120 V

What it welds

The Lincoln Electric K5255-1 Flux-Core Welder is a flux-core only on 120-volt input; its listing doesn't state an output range, so check the rating plate.

The maker's thickness claim reads "welds up to 1/4"".

The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.

As a flux-core machine it runs self-shielded wire with no gas bottle, which suits outdoor work; expect slag to chip off and less finesse on thin sheet.

A 120-volt machine runs from a household circuit, usually a 20-amp one per the manual. 120 V vs 240 V.

Eye protection: OSHA's minimum is shade 10 for most of this machine's range. Full table.

Also on the listing: a weight of 15 lb.

Warranty, per the listing: 12 months.

Is it the right machine for the job?

Buy it for

Outdoor and gasless repairs

Skip it for

Aluminium

What it does well, where it falls short

Does well

Runs on household 120 V
No gas bottle needed

Falls short

Duty cycle not stated with amps
120 V caps output
Slag cleanup
Output range not stated

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	K5255-1	Retailer
Power	Corded Electric	Retailer
Features (seller)	Portable	Retailer
Warranty	12 months	Retailer
Input power	120 V	Retailer
Product weight	15 lb	Retailer
Max steel (maker)	welds up to 1/4"	Retailer
