What it welds
The Everlast Power Equipment PowerArc161STH DC TIG Welder is a DC TIG with a maker-stated output of up to 140 amps on 240-volt input.
Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 140 amps at roughly 0.140 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: tig & stick. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.
It's DC TIG: steel, stainless and chromoly, but not aluminium.
It needs a 240-volt circuit; have a licensed electrician install the receptacle the manual specifies. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 8 for most of this machine's range (shade 10 for stick above 160 A). Full table.
Also on the listing: dimensions of 20 x 12.5 x 13.5 inches and a weight of 30.9 lb.
Is it the right machine for the job?
Buy it for
- Steel and stainless TIG
- Sheet metal to about 0.140 in
Skip it for
- Steel much past 0.140 in in one pass
- Aluminium
What it does well, where it falls short
Does well
- Up to 140 A output
Falls short
- Duty cycle not stated with amps
- Needs a 240 V circuit
- No aluminium (DC only)
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | PowerArc161STH | Retailer |
|---|---|---|
| Product weight | 30.9 lb | Retailer |
| Dimensions (seller) | 20 x 12.5 x 13.5 inches | Retailer |
| Material | Stainless Steel | Retailer |
| Power | dc | Retailer |
| Input power | 240 V | Retailer |
| Output range | 140 A | Retailer |
| Processes | tig & stick | Retailer |
| AC / DC | dc tig | Retailer |
Machines to put next to it
Other tig welders in the same amp range
- Sunstac TIG-250 TP ACDC AC/DC TIG Welder
- LOTOS TIG200ACDC AC/DC TIG Welder
- YESWELDER TIG-200P ACDC AC/DC TIG Welder
- AHP AlphaTIG 203Xi AC/DC TIG Welder
Every tig welders on one spec sheet · All Everlast Power Equipment machines listed
Final verdict
Made for steel and stainless TIG.
