YESWELDER BW-10MAXTRI Welding Helmet: 5 sensors, optical class 1/1/1/1

What it welds

The YESWELDER BW-10MAXTRI Welding Helmet is a passive.

Check that range against OSHA's minimums for your work: shade 10 for MIG from 60 to 500 amps, shade 8 for stick from 60 to 160 amps, shade 8 for TIG up to 150 amps. Shade chart.

Per the maker: 5 arc sensors; viewing area 8.89" x 3.23"; switching 1/30000s; optical class 1/1/1/1; power: Battery Powered. What each spec means.

Test the lens before every use; a lens that fails to darken exposes your eyes to the arc. Wear safety glasses with side shields under the helmet where chips can fly, as OSHA's fact sheet advises.

Also on the listing: dimensions of 10 x 2 x 50 inches and a weight of 2.79 lb.

Warranty, per the listing: 1 YEAR WARRANTY.

Is it the right machine for the job?

Buy it for

A backup or budget hood
Bench work

Skip it for

Work needing a shade outside its range
Low-amp TIG

What it does well, where it falls short

Does well

5 sensors
View 8.89" x 3.23"
Optical class 1/1/1/1

Falls short

Shade range not stated
Batteries to replace
Fixed shade

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	BW-10MAXTRI	Retailer
Product weight	2.79 lb	Retailer
Dimensions (seller)	10 x 2 x 50 inches	Retailer
Size	Large	Retailer
Material	PA	Retailer
Power	Battery Powered	Retailer
Warranty	1 YEAR WARRANTY	Retailer
Viewing area	8.89" x 3.23"	Retailer
Arc sensors	5	Retailer
Switching speed	1/30000s	Retailer
Optical class	1/1/1/1	Retailer
