What it welds
The Weldpro 155 Multi-Process Welder is a multi-process with a maker-stated output of up to 155 amps on 220-volt input.
By Miller's rule of thumb of 1 amp per 0.001 inch of steel, 155 amps reaches about 5/32 in in a single pass. Amps by thickness.
The maker's thickness claim reads "up to 1/4" steel". Makers often mean multiple passes or flux-core wire when a claim runs past the amps rule; the wording here says which.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: MIG/Gas MIG/MMA/Stick. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.
It needs a 240-volt circuit; have a licensed electrician install the receptacle the manual specifies. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 10 for most of this machine's range (shade 10 for stick above 160 A). Full table.
Also on the listing: dimensions of 14.96 x 13.58 x 6.69 inches and a weight of 21.2 lb.
Is it the right machine for the job?
Buy it for
- A shop that does a bit of everything
- Sheet metal to about 5/32 in
Skip it for
- Steel much past 5/32 in in one pass
What it does well, where it falls short
Does well
- Up to 155 A output
- Multi-process
Falls short
- Duty cycle not stated with amps
- Needs a 240 V circuit
- Torches may be extra
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | 155 | Retailer |
|---|---|---|
| Product weight | 21.2 lb | Retailer |
| Dimensions (seller) | 14.96 x 13.58 x 6.69 inches | Retailer |
| Size | 20.7 lb | Retailer |
| Material | Metal | Retailer |
| Power | gas_powered | Retailer |
| Input power | 220 V | Retailer |
| Wattage | 34.1 KW | Retailer |
| Output range | 155 Amp | Retailer |
| Max steel (maker) | up to 1/4" steel | Retailer |
| Wire sizes | 0.030"/0.035" | Retailer |
| Processes | MIG/Gas MIG/MMA/Stick | Retailer |
| Shielding gas | Gas/Gasless | Retailer |
Machines to put next to it
Other multi-process welders in the same amp range
- YESWELDER TIG-205P Multi-Process Welder
- TOOLIOM MIG-200 PRO Multi-Process Welder
- YESWELDER 185A Multi-Process Welder
- Weldpro 155GD Multi-Process Welder
Every multi-process welders on one spec sheet · All Weldpro machines listed
Final verdict
Made for A shop that does a bit of everything.
