What it welds
The YESWELDER SP200 MIG Welder is a MIG / gas with a maker-stated output of up to 200 amps on 110 or 220-volt input.
By Miller's rule of thumb of 1 amp per 0.001 inch of steel, 200 amps reaches about 0.200 in in a single pass. Amps by thickness.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: MIG/Flux Core/Spool Gun. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.
It runs solid wire under shielding gas for the cleanest wire-feed welds; most machines like it also run flux-core wire outdoors.
Dual-voltage input gives portability on 120 volts and full output on 240; the maker's ratings for each input differ. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 10 for most of this machine's range. Full table.
Also on the listing: a weight of 47 lb.
Is it the right machine for the job?
Buy it for
- Clean steel welds indoors
- Steel to about 0.200 in per pass
Skip it for
- Steel much past 0.200 in in one pass
What it does well, where it falls short
Does well
- Up to 200 A output
- Dual-voltage input
- Pulse: Pulsed MIG
Falls short
- Duty cycle not stated with amps
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | SP200 | Retailer |
|---|---|---|
| Product weight | 47 lb | Retailer |
| Material | Aluminum, Copper, Electronic Components, Insulation Materials, Iron, Plastic | Retailer |
| Power | ac | Retailer |
| Input power | 110 volts, 220 volts | Retailer |
| Wattage | 5.6 KW | Retailer |
| Output range | 200a | Retailer |
| Processes | MIG/Flux Core/Spool Gun | Retailer |
| Pulse | Pulsed MIG | Retailer |
| Spool gun | Spool Gun | Retailer |
Machines to put next to it
Other mig and flux-core welders in the same amp range
- Everlast Cyclone 200ES MIG Welder
- ESAB 700301082 MIG Welder
- Hobart 140EZ MIG Welder
- Forney 309 MIG Welder
Every mig and flux-core welders on one spec sheet · All YESWELDER machines listed
Final verdict
Built for clean steel welds indoors.
